Tilt Bucket
This HOPE tilt bucket is built for jobs where precision matters-ditching, grading, and fine grading work that requires clean, straight lines without moving the main excavator. It's not a standard bucket; it's a attachment designed to let you tilt the bucket hydraulically, so you can finish grades and ditches faster with fewer machine repositionings.
Unlike regular buckets that force you to shift the excavator back and forth, this tilt bucket swings via hydraulic cylinder. It hits a full 45° tilt, letting you shave slopes, clean trench bottoms, and edge materials smoothly right from your current position. That means less idle time, less wear on your tracks and undercarriage, and less fuel burned just to get the angle right.
The structure is heavy-gauge steel all around, reinforced at stress points, so it holds up in real construction and landscaping work. Moving parts are kept simple, so maintenance stays easy on site-no complicated systems to service, just regular greasing and visual checks.
Key Points
- 45° hydraulic tilt angle for exact grading, ditching, and sloping work
- Single-position operation - no need to reposition the excavator constantly
- Reduced machine wear & fuel use from less travel, less component stress
- Reinforced heavy-gauge build for long life in landscaping, utility, and light construction
- Wide fit across excavator sizes to match your fleet
Technical Specs
|
Model |
Suitable Weight (ton) |
Pin Diameter (mm) |
Pin Distance (mm) |
Length (mm) |
Width (mm) |
Height (mm) |
Arm Width (mm) |
|
HP-02 |
4-6 |
45 |
245 |
1200 |
790 |
920 |
170 |
|
HP-04 |
6-8 |
50 |
310 |
1400 |
870 |
1010 |
220 |
|
HP-06 |
12-18 |
60-65 |
360 |
1700 |
1070 |
1210 |
260 |
|
HP-08 |
19-24 |
80 |
465 |
1900 |
1200 |
1480 |
340 |
|
HP-10 |
25-36 |
90-100 |
530 |
2030 |
1360 |
1730 |
390 |
Best For
- Precision grading: Fine grading for driveways, pads, and landscaping slopes
- Drainage & utility trenching: Clean trench bottoms, side casting, and backfill shaping
- Slope work: Easy cutting of 1-side, 2-side, and cross slopes without repositioning
- Light material shaping: Spreading gravel, soil, and aggregate for smooth finishes
